| Domestic/Import |
: |
Import |
| End Style |
: |
FNPT |
| Finish |
: |
Galvanized |
| Fitting/Connector Type |
: |
Cap |
| Lee_Descr |
: |
I38SCAPGA - 3/8 STEEL CAP GALVANIZED |
| Lee_UPC |
: |
66254506474 |
| Material |
: |
Malleable Iron |
| Method of Manufacture |
: |
Cast |
| Nominal Size |
: |
3/8 in |
| Pressure Class |
: |
150 lb |
| Pressure Rating |
: |
150 psi |
| UPC_Lee |
: |
66254506474 |
| Weight |
: |
0.09 lb |
| Width |
: |
0.95 in |
| Length |
: |
1.0 in |
| Volume |
: |
0.71 cu-in |
| Height |
: |
0.75 in |
LEGEND Cap, Fitting/Connector Type: Cap, 3/8 in Nominal, FNPT, 150 lb, 150 psi, Cast, Malleable Iron, Galvanized, Import
- Better overall corrosion performance : Due to more smooth, even, and tougher surface coating with better adhesion as a result of superior electro-painting and double zinc coating process
- Clean bright finish that is much more aesthetically pleasing
- UL listed and factory mutual approved UL listings HHXX.EX6624 fire main equipment - pipe fittings and VIZQ.EX9172 sprinkler system and water spray system devices - unions
- Manufactured using the latest technologies for material consistency and dimensional tolerances, they're cast using an electric induction furnace, to ensure that the material is at optimum casting temperature longer
- Classified as a class 150 malleable iron fitting, (rated at 150 psi) they are test pressure rated by UL and factory mutual at 300 and 500 psi, configuration-specific
- Chinese fittings
