319426
LEGEND 114-706NLB T-596NL 1/4-Turn Ball Straight Stop Valve, 1/2 x 3/8 in Nominal, F1960 PEX x Compression End Style, 125 psi CWP Pressure, Brass Body, Import
Manufacturer: Legend
Brand: LEGEND
Lee Supply #: 319426
Manufacturer Part #: 114-706NLB
UPC: 66254513087
Customer Part #:
Sold As: 1/PK
Carmel
| Body Material | : | Brass |
| Dimensions | : | 2.99 in L |
| Domestic/Import | : | Import |
| End Style | : | F1960 PEX x Compression |
| Lee_Descr | : | 38.12BRSTRSTOPCH - 3/8" X 1/2" WIRSBO STRAIGHT STOP LEAD-FREE 114-706NLB |
| Lee_UPC | : | 66254513087 |
| Media | : | Water |
| Nominal Size | : | 1/2 x 3/8 in |
| Pressure Rating | : | 125 psi CWP |
| Series | : | T-596NL |
| Softgoods Material | : | NBR |
| Temperature Rating | : | 120 deg F |
| Trim Material | : | Brass/EPDM |
| Type | : | 1/4-Turn Ball |
| UPC_Lee | : | 66254513087 |
| Weight | : | 11.02 lb |
| Width | : | 8.35 in |
| Length | : | 11.05 in |
| Volume | : | 668.94 cu-in |
| Height | : | 7.25 in |
LEGEND Straight Stop Valve, Lead Free 1/4-Turn Ball, Series: T-596NL, 1/2 x 3/8 in Nominal, F1960 PEX x Compression, 125 psi CWP, Media: Water, Brass Body, Brass/EPDM Trim, NBR Softgoods, 120 deg F, 2.99 in L, Import
- Lead-free design is suitable for all lead-free potable water installations, in full compliance of all lead-free plumbing laws
- Proprietary cold-expansion PEX inlet connection utilizes an exaggerated center barb and PEX reinforcing ring (not included) for a permanent, leak-free connection
- 1/4-turn, self-cleaning ball valve design resists mineral and scale build-up, assuring positive shutoff and re-opening
- The ball-seat operation and dual O-ring stem seal features, out-perform traditional multi-turn stop designs
- Compact, chrome plated, forged brass bodies are both durable and decorative
- An ideal upgrade replacement for worn, leaking stops that won't close completely
- PEX barb inlet connection complies with ASTM F1960 and is designed for PEX tubing conforming to ASTM F876 and F877
- Manufactured in an ISO accredited facility
- Trim material - brass stem, EPDM seat
- Softgoods material - NBR stem O-ring
