| Amperage Rating | : | 2.8 A |
| Enclosure Type | : | NEMA 3 |
| Flow Rate | : | 13.2 gpm |
| Frequency Rating | : | 60 Hz |
| Impeller Type | : | NORYL FE1630PW PPE+PS-GS30 |
| Inlet Size | : | 1 in NPT |
| Lee_Descr | : | 98562817 - GRUNDFOS - SCALA2 1IN NPT - WATER CITY BOOSTER PUMP W/ NEMA 6-15P PLUG - 208-230V - WHOLE HOUSE - 148 MAX FEET OF HEAD - 145PSI MAX PRESSURE - DNR |
| Lee_UPC | : | 57114972338 |
| Material | : | NORYL FE1630PW PPE+PS-GS30 |
| Maximum Head | : | 147.6 ft |
| Maximum Pressure | : | 145 psi |
| Outlet Size | : | 1 in NPT |
| Phase | : | 1 |
| Power Rating | : | 0.7 hp |
| Series | : | SCALA |
| Temperature Rating | : | 32 to 113 deg F Ambient |
| UPC_Lee | : | 57114972338 |
| Voltage Rating | : | 208 to 230 V AC |
| Weight | : | 9.55 lb |
SCALA2 is a fully integrated water booster pump providing perfect water pressure in all taps at all times, even with multiple taps and showers running at the same time. It packs pump, motor, tank, sensor, drive and non-return valve into one compact unit. And with its intelligent pump control, SCALA2 automatically adjusts performance to both inlet pressure and water consumption in the home. Thanks to a water cooled motor, SCALA2 even offers one of the lowest noise levels of any booster on the market. SCALA2 features a built-in sensor, which constantly measures the discharge pressure. If the pressure drops below the desired level, SCALA2 boosts its operation immediately to compensate for the loss of pressure. We call it intelligent pump control and the result is perfect water pressure.
Grundfos Pressure Booster Pump, Series: SCALA, 13.2 gpm, 1 in NPT Inlet, 1 in NPT Outlet, 147.6 ft Maximum Head, 0.7 hp, 208 to 230 V AC, 2.8 A, 60 Hz, 1 ph, 145 psi Maximum, NORYL FE1630PW PPE+PS-GS30 Impeller, 32 to 113 deg F Ambient, NEMA 3, NORYL FE1630PW PPE+PS-GS30
- Perfect water pressure
- Low noise
- Easy selection
- Easy installation
- Easy to operate
- Reliability, long lifetime
