| Amperage Rating | : | 5.2 A |
| Bearing Type | : | Thrust |
| Enclosure Type | : | IP68 |
| Flow Rate | : | 8.83 gpm |
| Frequency Rating | : | 50/60 Hz |
| Impeller Type | : | Floating |
| Lee_Descr | : | 96160140 - GRUNDFOS - 10SQ05-160 230V 3IN - 1-1/4NPT - SQ-SERIES DEEP WELL SUBMERSIBLE PUMP - 1/2HP - 160 MAX FEET OF HEAD - 2 WIRE - 10GPM - 10SQ05160230 |
| Lee_UPC | : | 57003986941 |
| Material | : | Stainless Steel |
| Maximum Suction Lift | : | 11.52 ft |
| Motor Speed | : | 10700 rpm |
| Number of Stages | : | 3 |
| Number of Wires | : | 2 |
| Phase | : | 1 |
| Power Rating | : | 1/2 hp |
| Series | : | SQ Series |
| Temperature Rating | : | 68 deg F |
| UPC_Lee | : | 57003986941 |
| Voltage Rating | : | 200/240 V AC |
| Weight | : | 4.8 lb |
The Grundfos SQ 3 in submersible pumps offer a wide performance range, making it easy to find a model that will suit your individual requirements. The SQ is a compact, 3 in multi-stage centrifugal pump that can be installed in a borehole no larger than the pump itself. With their built-in electronics, SQ pumps are very easy to install and operate, while guaranteeing a reliable water supply at all times. Equipped with permanent magnet motors, these flexible and compact pumps offer excellent efficiency levels and will supply pump heads up to 656 ft (200 m). If the SQ pump is connected to the Grundfos CU 301 control box, it enables the creation of a constant pressure water supply.
Grundfos, 96160140, Submersible Pump, Series: SQ Series, 8.83 gpm Flow Rate, 2 Wires, 3 Stage, 11.52 ft Maximum Suction Lift, 1/2 hp Power, 200/240 V AC, 5.2 A, 50/60 Hz Frequency, 1 ph, 10700 rpm Motor, Floating Impeller, 68 deg F, IP68 Enclosure, Thrust Bearing, Stainless Steel
- Dry running protection
- Permanent magnet motor with high efficiency
- Wear resistance from floating impellers
- Protection against up thrust
- High flow velocity
- Soft start - Reduces wear on motor and minimizes stress of the entire installation
- Over and under voltage protection
- Overload protection
- Over temperature protection
- Unique 3 in design
- Wide voltage window
- Automatic restart
- All stainless steel exterior design reduces risk of corrosion to a minimum
- High starting torque and deep setting handling
- No extra box needed
- Handle voltage fluctuation, protection and automatic restart
- Compact, built-in electronics
- High efficiency
- Basic version without communication
