| Amperage Rating | : | 0.53 to 0.75 A |
| Dimensions | : | 5-8/16 in W x 6-8/16 in H |
| Flow Rate | : | 25.1 gpm |
| Frequency Rating | : | 60 Hz |
| Lee_Descr | : | 59896773 - GRUNDFOS - UPS15-55SFC - 1-1/4 FLANGED - RECIRCULATING PUMP - STAINLESS STEEL - 1/12HP - 115V - 3SPEED - 18 MAX FEET OF HEAD - 25GPM - |
| Lee_UPC | : | 837414449 |
| Maximum Head | : | 18.05 ft |
| Maximum Pressure | : | 145 psi |
| Phase | : | 1 |
| Power Rating | : | 87 W |
| Series | : | UPS |
| Temperature Rating | : | 104 deg F |
| UPC_Lee | : | 837414449 |
| Voltage Rating | : | 115 V AC |
The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. The pump has 3-step speed selector.
Grundfos Circulator Pump, Series: UPS, 25.1 gpm, 18.05 ft Maximum Head, 87 W, 115 V AC, 0.53 to 0.75 A, 60 Hz, 1 ph, 145 psi Maximum, 104 deg F, 5-8/16 in W x 6-8/16 in H
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Stainless steel pump housing
- 1 ph motor, no additional motor protection is required
