| Amperage Rating | : | 1.3 to 1.8 A |
| Dimensions | : | 6 in W x 6-1/2 in H |
| Flow Rate | : | 33 gpm |
| Frequency Rating | : | 60 Hz |
| Lee_Descr | : | 52722512 - GRUNDFOS - UPS2699FC - 1IN FLANGED - RECIRCULATING PUMP - 3-SPEED - CAST IRON - 1/6HP 15/26 FLANGE - 115V - 28.9 MAX FEET OF HEAD - 33GPM - |
| Lee_UPC | : | 834818707 |
| Maximum Head | : | 28.87 ft |
| Maximum Pressure | : | 145 psi |
| Motor Speed | : | 3380 rpm |
| Phase | : | 1 |
| Power Rating | : | 197 W |
| Series | : | UPS |
| Temperature Rating | : | 104 deg F |
| UPC_Lee | : | 834818707 |
| Voltage Rating | : | 115 V AC |
| Weight | : | 10.3 lb |
The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.
Grundfos Circulator Pump, Series: UPS, 33 gpm, 28.87 ft Maximum Head, 197 W, 115 V AC, 1.3 to 1.8 A, 60 Hz, 1 ph, 145 psi Maximum, 3380 rpm Motor, 104 deg F, 6 in W x 6-1/2 in H
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Cast iron pump housing
- 1 ph motor, no additional motor protection is required
